  • Aluminum Profile Single Head Cutting Machine
  • Aluminum Profile Single Head Cutting Machine
Aluminum Profile Single Head Cutting MachineAluminum Profile Single Head Cutting Machine

Aluminum Profile Single Head Cutting Machine

  • Product Item : LJZ-500
  • Brand: OKNA
  • Color: gray/white
  • Country of Origin: China
  • Application: Designed for PVC & aluminum profiles cutting
  • Product description:Aluminum single head cutting machine is primarily used for cutting PVC and aluminum window profiles, also used for cutting plastic material, single head sawing machine for aluminum, aluminum single h
  • Inquiry

Aluminum window single head cutting machine

Product description

1. This aluminum single head cutting machine is primarily used for cutting industrial auminum profile and aluminium win-door profiles also used for cutting PVC window profiles.
2. It utilizes hard alloy saw blade for external diameter is as big as 20 inches, the linear speed is high, and the processing precision is high.
3. The cutting saw is equipped with a positioning rack, and an optional digital display device can be installed on the machine as per the customer’s request, resulting in accurate positioning.
4. So it is an ideal choice for cutting extra-thick industrial aluminum profile, aluminum doors and windows, and curtain wall profiles.
5. High precision linear guiding pair push the saw blade feeding on down to up which ensured steady and long-term processing accuracy.

6. According to the production requirements of aluminum alloy windows, the profile can be cut at 45 degree and 90 degree.

7. Power supply protects system from voltage overload.
Technical Description

Power supply
380V/50Hz
Total power
3Kw
Working air pressure 0.5~0.8MPa
Air consumption
10L/min
Diameter of blade
500mm
principal axis rotate speed
2800r/min
Cutting heigth
150mm
Cutting width
230mm
Dimensions:(Width×Depth×Height)
1200×1300×1200mm
Weight when empty
300Kg

*All specifications, dimensions, colors, and design characteristics are shown in this aluminum profile single head cutting machine are subject to change without notice.
